Coal Mine & Methane Flow Meter Applications

Accurate Measurement of Methane Gas Recovery from Coal Beds

Using our award-winning thermal mass flow measurement technology, Fox Thermal meters can monitor the flow of methane in coal mining methane recovery processes, providing accurate greenhouse gas (GHG) emissions reporting for environmental regulations, as well as submetering captured methane to be used as an energy source.

Fox Thermal Coal Mine & Methane Flow Meters Provide

Accuracy Even at Very Low Flow Rates

Our flow measurement technology provides direct thermal mass flow measurement of air or gas in standard volumetric or mass units and provides an exceptionally broad measurement range, (up to 1000:1; with 100:1 typical) including very low-velocity flow rates for methane recovery.

Calibration Validation in the Field

Calibration Validation available with the CAL-V™ feature on some Fox Thermal mass flow meter models ensures that the meter still retains its original NIST-traceable calibration to ensure the meter is operating accurately in the field for methane flow measurement and GHG emissions reporting.

Easy Adjusting of Gas Compositions

Fox Thermal flow meter models FT1, FT4A, and FT4X come with gas selection menus available with the Gas-SelectX® feature. Ideal for coal mine emissions flow measurements, users update gas selections when the composition changes over time for a new gas mixture that can be re-set in the field.

Coal Mine & Methane Flow Meter Applications

Coal mines must monitor and report greenhouse gas (GHG) emissions to comply with the EPA’s Title 40 CFR Part 98 Subpart FF. Fox Thermal gas flow meters can measure the flow of GHG emissions for reporting purposes.

Methane is most commonly ventilated, flared, or recovered in coal mining, and coal mine methane (CMM) is a potent greenhouse gas that, if vented to the atmosphere, contributes to climate change. If not vented, however, CMM can create an explosive hazard inside the mine. Nevertheless, if CMM is recovered safely and used for energy, it is a valuable, clean-burning fuel source.

Three major sources of CMM:

  • Degasification systems (drainage) both pre-mine and gob
  • Ventilation air (VAM)
  • Abandoned or closed mines

The Fox Thermal Calibration Lab employs a wide range of gases, gas mixtures, pressures, temperatures, and line sizes to simulate actual fluid and process conditions. This real-world approach allows Fox Thermal Gas Mass Flow Meters to help mining operations comply with regulations, improve the operation of co-gen engines or methane oxidizers, and facilitate the data management processes needed to monetize greenhouse gas emission reduction.

Help Me Choose A Flow Meter
Greenhouse gas emissions monitoring

Coal Bed Methane Recovery

Coal production continues to fall year over year, as the power/energy sector moves toward cleaner, more sustainable fuel sources. But coal, even in abandoned mines, still emits methane.

Natural gas, or methane, can be extracted from deep underground in coal beds. Coal Bed Methane (CBM) as a clean-burning fuel source is expected to increase as more regulations force energy companies to move away from processes that produce high levels of CO2 emissions, like coal-burning plants.

Coal is a very porous material and coal beds generally have ground water flowing through the seams. This ground water exerts pressure on the coal which holds methane gas on the surface of and in the pores of the coal. To release the methane, the water must be pumped 300 – 3,000 feet up to the surface where it can be separated from the water and used as fuel. CBM has very low solubility in water and readily separates as pressure decreases, allowing it to be piped out of the well separately from the water.

As technological advances are made, as incentives to reduce greenhouse gases increase, and as environmental pressure intensifies, the benefits of capturing and using CMM or CBM as fuel gases become more significant. Fox Thermal Flow Meters’ accuracy specification exceeds the requirements defined by the EPA and helps provide a reliable, cost-effective solution for GHG emissions monitoring challenges. At the same time, our flow meters ensure accurate measurement of the fuel gas produced.

Fox Thermal Flow Meters for Coal Bed Methane Recovery

Gas-SelectX® for Superior Coal Mine & Methane Flow Meter Applications

Gas-SelectX® allows the user to define the gas composition settings in the flow meter as it changes without returning the flow meter to the factory for recalibration. This makes flow meters with the Gas-SelectX® option ideal for coal mine emissions flow measurements because the emissions may not be 100% methane and may change over time.

Users can choose from a list of multiple gases to create a customized gas mix. The gas mixes are programmable in 0.1% increments. The Gas-SelectX® feature can be accessed in the field through the front panel of the meter or by using the appropriate free software tool.

The Fox Thermal Model FT4A is equipped with the Gas-SelectX® feature, making it ideal for coal mine emissions flow measurements.

How to Get Flow Meters for Coalbed Methane Recovery & GHG Monitoring

Our new app can help you choose the right flow meter model fast.

If you’re not sure which flow meter is right for your needs, our Help Me Choose app walks you through a short series of questions to help you choose the ideal meter.

Fill out the details in the configurator form

Next, enter your process data and measurement requirements into our automated product configurator. Drop-down menus and Help icons will guide you to answer each question.

An expert from Fox Thermal will contact you with a quote

Save the data you entered into the configurator to create a PDF with a model code and application ID. When you're ready, submit your application to Fox Thermal for a quote.

Discover the Fox Thermal Advantage

Flow Meters for Coal Mine & Methane Applications

fox thermal product ft1

Model FT1

ThThe Model FT1 measures gas flow rate/total and temperature for industrial processes, including coal bed methane monitoring. It comes equipped with the Direct Digitally Controlled DDC-Sensor™, the Gas-SelectX® gas selection menu, and calibration validation with the CAL-V™ feature for NIST-traceable calibration.

Model FT1
fox thermal product ft2A meter

Model FT2A

The Fox Thermal Model FT2A gas flow meter has a large selection of communication protocol options available intrinsically. Options include BACnet MS/TP, RS485 Modbus RTU, Profibus-DP, DeviceNet, or Ethernet Modbus TCP. NEMA 4X approved for hazardous locations.

Model FT2A
fox thermal product ft3 meter

Model FT3

The Model FT3 was designed with oil & gas customers in mind. This meter is Quad O (OOOO) compliant and is perfect for use in flare gas applications along with other fuel gas measurements, including sub-metering. It includes the CAL-V™ and Zero CAL-CHECK® features for NIST-traceable calibration.

Model FT3
fox thermal product ft4A meter

Model FT4A

The Fox Thermal Model FT4A includes the Gas-SelectX® gas selection menu and the CAL-V™ calibration validation feature. It is CE, FM, and FMc approved, along with ATEX and IECEx. Applications include gas separators and vapor recovery units.

Model FT4A
fox thermal product ft4X meter

Model FT4X

The Fox Thermal Model FT4X thermal gas mass flow meter comes with a BLM accuracy-compliant data logger which maintains a 7-year history. Includes the Gas-SelectX® & CAL-V™ features and is specially designed for all types of oil & gas applications, including coal mine methane emissions monitoring and resale.

Model FT4X
